Theben DIMAX 540 APP B App-Controlled Mini Flush Dimmer

Description

Theben DIMAX 540 APP B App-Controlled Mini Flush Dimmer

Theben 5400230

  • Universal flush-mounted dimmer for retrofit applications
  • App-based control via Bluetooth mesh network
  • Suitable for incandescent, halogen, and LED loads
  • No neutral wire required for simplified installation
  • Compact design for easy integration in existing setups
  • Memory function and adjustable minimum brightness
  • Integrated protection against overheating, overcurrent, and short circuits
  • Supports cable lengths up to 100 m for extended two-way circuits

Theben DIMAX 540 APP B is a compact universal dimmer designed for modern lighting control in both new and retrofit installations. With app-based operation and Bluetooth mesh connectivity, it provides convenient remote access while maintaining reliable performance for resistive and capacitive loads. Its flush-mounted format, fully encapsulated electronics, and wiring concept without a neutral conductor make installation straightforward in existing systems. Ideal for professional lighting applications, it combines practical flexibility with robust protective functions and efficient stand-by consumption.

.

Product type Dimmer
Operating voltage 230 V AC
Frequency 50 - 60 Hz
Installation type Flush-mounted
Stand-by consumption < 0.5 W
Incandescent/halogen lamp load 150 W
LED lamp 2-8 W 150 W
Programmierung per App +
Multi-function -
Setting App
Load detection -
Max. cable length 100 m
Ambient temperature -10°C ... 45°C
Length 33 mm
Width 27 mm
Height 10 mm
Net Weight 15 g

Read more

Theben DIMAX 540 APP B App-Controlled Mini Flush Dimmer

Product form

SKU: 5400230

Theben DIMAX 540 APP B App-Controlled Mini Flush Dimmer Theben 5400230 Universal flush-mounted dimmer for retrofit applications App-based control via... Read more

£50.01 ex VAT £60.01 inc VAT

Available 1-3 working days  This product is ordered directly from the supplier, as it is not stocked in our warehouse. The displayed ETA reflects the estimated time for us to delivery your order.

    • Guaranteed secure & safe checkout.

      shop pay
    • Free shipping on all orders above £100 + vat
      Specification
    Product type Dimmer
    Operating voltage 230 V AC
    Frequency 50 - 60 Hz
    Installation type Flush-mounted
    Stand-by consumption < 0.5 W
    Incandescent/halogen lamp load 150 W
    LED lamp 2-8 W 150 W
    Programmierung per App +
    Multi-function -
    Setting App
    Load detection -
    Max. cable length 100 m
    Ambient temperature -10°C ... 45°C
    Length 33 mm
    Width 27 mm
    Height 10 mm
    Net Weight 15 g
      Downloads

    Description

    Theben DIMAX 540 APP B App-Controlled Mini Flush Dimmer

    Theben 5400230

    • Universal flush-mounted dimmer for retrofit applications
    • App-based control via Bluetooth mesh network
    • Suitable for incandescent, halogen, and LED loads
    • No neutral wire required for simplified installation
    • Compact design for easy integration in existing setups
    • Memory function and adjustable minimum brightness
    • Integrated protection against overheating, overcurrent, and short circuits
    • Supports cable lengths up to 100 m for extended two-way circuits

    Theben DIMAX 540 APP B is a compact universal dimmer designed for modern lighting control in both new and retrofit installations. With app-based operation and Bluetooth mesh connectivity, it provides convenient remote access while maintaining reliable performance for resistive and capacitive loads. Its flush-mounted format, fully encapsulated electronics, and wiring concept without a neutral conductor make installation straightforward in existing systems. Ideal for professional lighting applications, it combines practical flexibility with robust protective functions and efficient stand-by consumption.

    .

    Product type Dimmer
    Operating voltage 230 V AC
    Frequency 50 - 60 Hz
    Installation type Flush-mounted
    Stand-by consumption < 0.5 W
    Incandescent/halogen lamp load 150 W
    LED lamp 2-8 W 150 W
    Programmierung per App +
    Multi-function -
    Setting App
    Load detection -
    Max. cable length 100 m
    Ambient temperature -10°C ... 45°C
    Length 33 mm
    Width 27 mm
    Height 10 mm
    Net Weight 15 g

    Read more
