Theben LUNA 111 top3 EL Twilight Switch DIN rail Digital built-in light sensor

Description

Theben LUNA 111 top3 EL Twilight Switch DIN rail Digital built-in light sensor

Theben 1110230

  • Digital twilight switch for DIN rail mounting with one channel
  • Operating voltage: 110 V AC to 230 V AC, 50/60 Hz
  • Brightness setting range: 1 to 99,000 lx
  • Adjustable switch-on and switch-off delay from 0 to 59 minutes
  • Switching capacity up to 16 A at 250 V AC, cos ? = 1
  • Suitable for LED loads up to 600 W and high inrush currents up to 800 A / 200 µs
  • Separate built-in light sensor with IP66 protection
  • App-based programming via optional Bluetooth OBELISK top3 for secure tamper-resistant setup
  • Robust housing made of high-temperature resistant, self-extinguishing thermoplastic
  • Compact design with hour counter, power reserve, and DuoFix plug-in terminals

Engineered for reliable daylight-dependent lighting control, the Theben LUNA 111 top3 EL combines precision, flexibility, and ease of use in a compact DIN rail format. Its wide brightness range, configurable time delays, and powerful switching performance make it an efficient solution for modern lighting installations. With secure app-based programming and a durable sensor system, it supports professional applications where dependable automation and long-term operational quality are essential.

.

Brand Theben
Product type Digital twilight switch
Installation type DIN rail
Operating voltage 110 V AC - 230 V AC
Frequency 50 - 60 Hz
Stand-by consumption ~0.8 W
Brightness setting range 1 - 99000 lx
Switch-on delay 0 - 59 min
Switch-off delay 0 - 59 min
Type of contact Changeover contact
Switching capacity 16 A at 250 V AC, cos ? = 1; 10 A at 250 V AC, cos ? = 0.6
Inrush current Max. 800 A / 200 µs
Housing material High-temperature resistant, self-extinguishing thermoplastic
Protection class II, Sensor III
Max. cable length to sensor 100 m
Dimensions 69 x 35 x 90 mm
Net weight 128 g

Read more

Theben LUNA 111 top3 EL Twilight Switch DIN rail Digital built-in light sensor

Product form

SKU: 1110230

Theben LUNA 111 top3 EL Twilight Switch DIN rail Digital built-in light sensor Theben 1110230 Digital twilight switch for DIN... Read more

£283.07 ex VAT £339.68 inc VAT

Available 10-16 working days  This product is ordered directly from the supplier, as it is not stocked in our warehouse. The displayed ETA reflects the estimated time for us to delivery your order.

    • Guaranteed secure & safe checkout.

      shop pay
    • Free shipping on all orders above £100 + vat
      Specification
    Brand Theben
    Product type Digital twilight switch
    Installation type DIN rail
    Operating voltage 110 V AC - 230 V AC
    Frequency 50 - 60 Hz
    Stand-by consumption ~0.8 W
    Brightness setting range 1 - 99000 lx
    Switch-on delay 0 - 59 min
    Switch-off delay 0 - 59 min
    Type of contact Changeover contact
    Switching capacity 16 A at 250 V AC, cos ? = 1; 10 A at 250 V AC, cos ? = 0.6
    Inrush current Max. 800 A / 200 µs
    Housing material High-temperature resistant, self-extinguishing thermoplastic
    Protection class II, Sensor III
    Max. cable length to sensor 100 m
    Dimensions 69 x 35 x 90 mm
    Net weight 128 g
